In Silicon Valley startups, Docker Compose is one of the preferred tools for quickly deploying and managing containerized applications. However, convenience often comes with security risks. As a Site Reliability Engineer (SRE), I am well aware that security vulnerabilities can lead to catastrophic consequences. This article will share the best security practices I have summarized in my actual work combining Docker Compose with Ubuntu systems, helping you enjoy the convenience of Docker Compose while ensuring system security.
Before deploying containers, it is crucial to ensure the security of the Ubuntu host itself. Here are some key steps:
Ensure that both the system and Docker are kept up-to-date to fix known vulnerabilities:
sudo apt update && sudo apt upgrade -y
sudo apt install docker-ce docker-compose-plugin
Strictly control Docker management permissions to prevent privilege escalation attacks:
sudo usermod -aG docker deployuser
Reasonably restrict network access to prevent unauthorized access:
sudo ufw allow OpenSSH
sudo ufw allow 80/tcp
sudo ufw allow 443/tcp
sudo ufw enable
sudo ufw status verbose
By default, Docker bypasses UFW to configure iptables, so manual control is recommended:
Modify the Docker configuration file:
sudo nano /etc/docker/daemon.json
Add the following content:
{
"iptables": false,
"ip-forward": true,
"userland-proxy": false
}
Restart the Docker service:
sudo systemctl restart docker
Explicitly bind addresses in Docker Compose:
services:
webapp:
ports:
- "127.0.0.1:8080:8080"
The following configurations apply to Docker Compose v2.4 and above. Note the differences between non-Swarm and Swarm modes.
Containers running as root by default pose high risks; change to non-root users:
services:
app:
image: your-app:v1.2.3
user: "1000:1000"
read_only: true
volumes:
- /tmp/app:/tmp
cap_drop:
- ALL
cap_add:
- NET_BIND_SERVICE
Explanation:
- A read-only filesystem prevents tampering within the container.
- Ensure mounted volumes are limited to necessary directories.
Precisely divide internal and external networks to avoid exposing sensitive services to the public:
networks:
frontend:
internal: false
backend:
internal: true
services:
nginx:
networks: [frontend, backend]
database:
networks:
- backend
- Frontend network: Can be open to the public.
- Backend network: Strictly restricted, internal communication only.
Sensitive data should never be placed directly in Compose files:
In single-machine mode:
services:
webapp:
environment:
- DB_PASSWORD_FILE=/run/secrets/db_password
volumes:
- ./secrets/db_password.txt:/run/secrets/db_password:ro
In Swarm mode:
services:
webapp:
secrets:
- db_password
environment:
DB_PASSWORD_FILE: /run/secrets/db_password
secrets:
db_password:
external: true
Note:
- Docker's native Swarm Secrets cannot directly use external tools like Vault or AWS Secrets Manager.
- If external secret storage is needed, integrate the reading process yourself.
Container resource limits prevent a single container from exhausting host resources.
Docker Compose Single-Machine Mode (v2.4 recommended):
version: '2.4'
services:
api:
image: your-image:1.4.0
mem_limit: 512m
cpus: 0.5
Docker Compose Swarm Mode (v3 and above):
services:
api:
deploy:
resources:
limits:
cpus: "0.5"
memory: 512M
reservations:
cpus: "0.25"
memory: 256M
Note: In non-Swarm environments, the deploy section's resource limits do not take effect, be sure to pay attention to the Compose file version.
Set up health checks to proactively detect issues and reduce service downtime:
services:
webapp:
healthcheck:
test: ["CMD", "curl", "-f", "http://localhost/health"]
interval: 30s
timeout: 10s
retries: 3
start_period: 20s
Avoid the uncertainty brought by the latest tag in production environments, enforce specific image versions:
services:
api:
image: your-image:1.4.0
Prevent container logs from exhausting disk space:
services:
web:
logging:
driver: "json-file"
options:
max-size: "10m"
max-file: "5"
By default, Ubuntu enables AppArmor, and it is recommended to check the Docker profile status:
sudo systemctl enable --now apparmor
sudo aa-status
Docker on Ubuntu defaults to enabling AppArmor without additional configuration. It is generally not recommended to enable SELinux on Ubuntu simultaneously to avoid conflicts.
- Image Vulnerability Scanning: It is recommended to integrate tools like Trivy, Clair, or Snyk in the CI/CD process:
docker run --rm -v /var/run/docker.sock:/var/run/docker.sock \
aquasec/trivy image your-image:v1.2.3
- Automated Security Update Process: Rebuild images at least weekly to fix known vulnerabilities.
In July 2019, Capital One suffered a major data breach affecting the personal information of over 100 million customers 12. Although the main cause of this attack was AWS configuration errors, it also involved container security issues similar to your described situation:
- Container Permission Issues: The attacker exploited a vulnerability in a Web Application Firewall (WAF) running in a container but with excessive permissions.
- Insufficient Network Isolation: The attacker could access other AWS resources from the compromised container, indicating insufficient network isolation measures.
- Sensitive Data Exposure: Due to configuration errors, the attacker could access and steal a large amount of sensitive customer data.
- Security Configuration Mistakes: The root cause of the entire incident was the accumulation of multiple security configuration errors, including container and cloud service configuration issues.
This incident resulted in significant financial losses and reputational damage for Capital One. It is reported that the company faced fines of up to $150 million due to this incident, along with a long-term trust crisis. This case highlights the importance of security configuration in container and cloud environments, especially in permission management, network isolation, and sensitive data protection. It reminds us that even seemingly minor configuration errors can be exploited by attackers, leading to disastrous consequences.
Docker Compose combined with Ubuntu is a convenient way to quickly deploy container applications, but security must be integrated throughout the entire process:
- Strictly control container permissions and network isolation.
- Avoid sensitive data leaks.
- Regular security scanning and updates.
- It is recommended to migrate to advanced orchestration systems like Kubernetes for stronger security assurance as the enterprise scales.
Security is a continuous practice with no endpoint. I hope this article helps you better protect your Docker Compose + Ubuntu deployment environment.
